PIR Cold room panel

Brand Name： SDpanel

Style: 　PIR cold room Panel

Length: ≤11800 mm

Width ： 1000 mm

Panel Thickness:5 0 mm/75 mm/100 mm/150 mm/200 mm

Core Materials: PIR

Outer Plate Material: PPGI PE/PVDF/HDP

External skin thickness： 0.4 mm–0.5 mm

Inner skin thickness： 0.4 mm–0.5 mm

MOQ： 500 units

Delivery Time :30 days

The PIR cold room panel has the advantages of flame retardancy , thermal insulation, compression resistance, energy saving and environmental protection. Taking lightweight polyurethane as the inner material of the cold room panel, the advantage of polyurethane is that the thermal insulation performance is very good. The exterior of the PIR cold room panel is made of color steel plate or stainless steel plate components .

Description of PIR Cold Room Panel

The cold room panel is consisted by an inner metal plate, an outer metal plate, and an intermediate polyurethane insulation layer. SDpanel polyurethane insulated panel for cold storage can be produced with a thickness of 50 mm-250 mm. The appearance of the panelis of pressed in compression bar or clear surface. The thickness of the color coated steel plate is 0.4 mm-0.8 mm. The effective width of the cold room panel is 1120 mm.

Advantages of PIR Cold Room Panel

The choice of PIR sandwich panels as cold storage panels is based on the characteristics of the PIR sandwich panels themselves.

Insulation Properties

PIR foam has a closed cell structure with a closure rate of more than 90%, making it an excellent insulating material with a low thermal conductivity, which means that it significantly reduces heat transfer, keeping the interior of the building warmer in winter and cooler in summer.

High quality joints

SDpanel’s PIR cold room panels are designed with high-quality dry joints to minimize heat loss at the panel joints, giving the PIR sandwich panels the best possible advantage.
