Steel strip edge rock wool sandwich panel

Brand Name： SDpanel

Style: 　Steel strip edge rock wool sandwich panel

Length: ≤11800 mm

Width ： 1000 mm

Panel Thickness:5 0 mm/75 mm/100 mm/150 mm/200 mm

Core Materials: Rock Wool

Outer Plate Material: PPGI PE/PVDF/HDP

External skin thickness： 0.4 mm–0.5 mm

Inner skin thickness： 0.4 mm–0.5 mm

MOQ： 500 units

Delivery Time :20 days

Different from PU edge sandwich panel, this kind of rock wool sandwich panel is sealed with steel strips, Steel strip edge rock wool sandwich panel is the first generation of rock wool sandwich panel, its biggest advantage is cheap, which is the best choice for customers who are looking for cost.

Introduction of Steel strip edge rock wool sandwich panel

Steel strip edged rock wool sandwich panel is a non-combustible structural rock wool as the core material, galvanized or aluminum-zinc-plated color-coated steel plate as the finish, the ends are edged with ordinary steel strips, and through the professionally researched and developed adhesive, the two form an interactive composite energy-saving building panel.

Advantages of steel strip edge rock wool sandwich panel

Excellent fire protection

The raw materials, production process and formula used in the steel strip sealing rock wool sandwich panel make it have good fire resistance. Test surface shows that it has fire resistance exceeding 1000℃. The steel strip sealed rock wool sandwich panel has passed the test of GIOROANO S.P.A, an authoritative Italian testing agency.

Sound Insulation

Steel strip edge rock wool sandwich panels have a significant effect on noise transmission.Rock wool sandwich panels have a significant effect on noise transmission. It is widely used in some noisy areas. Through testing, according to ISO 717/82 and UNI 8270/7 standards, the use of 120 kg/m³ density of rock wool as the core material of the sandwich panels, the sound insulation effect can reach RW = 29-30 dB.

Corrosion Resistant

Steel strip edge rock wool sandwich panel is not affected by acid and alkali, can adapt to acid and alkali environment, has good corrosion resistance. Steel strip edge rock wool sandwich panels are used in some corrosion-prone buildings, such as chemical plants, food production plants. Therefore, the life of rock wool sandwich panel can reach up to 20 years.
